Apple’s detailed app review process has resulted in greater security
for iOS apps made available through the App Store. However, this
review process can be lengthy, which negatively impacts developers who
need to quickly patch a buggy or insecure app. As a result, we have
seen the development of various third-party solutions that allow
developers to remotely hot patch an iOS app on a non-jailbroken device
without going through Apple’s review process. While iOS remote hot
patching is a very recent concept and is still in its inception, we
have seen fierce demand and an emerging market for such products.
However, they are not without their own security risks.
In our January blog, we discussed JSPatch, an
open source hot patching solution. While JSPatch allows developers to
provide better support to users by quickly fixing problematic apps, it
potentially allows malicious actors to engage in attacks that evade
current iOS security controls.
In this episode, we take
you on a tour of Rollout.io, a commercial (though currently with
limited free access) solution that attempts to address the remote
patching problem with an eye towards security.
According to their website, Rollout is an Israel-based, venture
capital-backed technology startup founded in 2014. The core product is
a commercialized solution to the iOS patching problem that essentially
allows developers to update their app’s behavior, following an app’s
initial approval and release, without going through Apple’s App Store
review process.
Co-founder Erez Rusovsky stated that
Rollout “created an SDK that allows you to remotely hot-patch native
production applications”. Rollout’s mission statement further states
that:
Rollout.io’s mission is to bridge the gap between
developers and their live apps. When a live app needs updating, app
developers usually wait days and even weeks to get the new version out
to their users. Rollout solves this problem by giving developers
code-level access to their live apps.
Rollout is aware of
the concerns within the community that patching apps outside of the
App Store could be a violation of Apple’s review guidelines and
practices. Rollout notes both on their FAQ site and in a longer blog post that
their process is in compliance.
JSPatch, which we discussed in our previous blog, provides a
relatively simple patching framework consisting of three Objective-C
files to be imported to an iOS app to activate the remote hot patching
capability. As a commercial offering, Rollout offers a software
development kit (SDK) and infrastructure that supports patching for
scale and efficiency. Rollout provides a simple overview of their
process, but also gives us an insider look into the tech stack and the
“under the hood” mechanics of their Rollout SDK through their
technical blogs. For our analysis, we focus only on the dissection of
the Rollout SDK.
In a nutshell, Rollout SDK is built on
the following three technologies:
● dSYM file
● Method Swizzling
● JavaScriptCore framework
According to Rollout, the following steps are taken for an app to
hook up with Rollout:
The developer chooses to use Rollout SDK
and imports the SDK into their app.
The Rollout SDK parses the
app code and generates the dSYM file (debug symbol file), which is
uploaded to Rollout’s back end.
The dSYM file is rendered in the
developer portal and available to the app developer for use in
reviewing and patching an app.
The end result is rendered by Rollout’s developer portal and
presented to the developers, allowing them to select and patch a
function. Through the Rollout portal, the developer has easy access to
all the defined classes (e.g. ViewController) and selectors (e.g.,
imagePickerController:didFinishPickingMediaWithInfo:) of the analyzed
app, as shown in Figure 1.
Figure 1: Rollout developer
portal allowing the developer easy access to all defined classes and
methods in the app
The most common way to patch a bug in an existing
function is to replace the faulty implementation of the function with
a new, fixed one. But there are situations where a fix is needed in
multiple places across the application. In this case, the best
practice is to create a new function that encapsulates the shared
routine. In Rollout, one can easily achieve this through the interface
shown in Figure 2.
Figure 2: Rollout developer portal
allowing the developer to add a new method into a class
Rollout also allows developers to resolve problematic
situations such as when a method was renamed but still called from some
code in the UI, which requires the developer to link the
disconnect by a new wrapper method. In this case, selecting a function
to be fixed (such as [ViewController
imagePickerController:didFinishPickingMediaWithInfo:] shown in Figure
2) will display the JavaScript patch editing interface shown in Figure
3.
Figure 3: Rollout develop portal
providing a JavaScript editing interface for patch development
Method swizzling is known to iOS developers as
“black magic.” In short, method swizzling is an Objective-C
runtime technique that allows one implementation of a method to
replace an existing implementation of another method (of a class or
instance) at runtime.
The term “implementation” refers to
the actual function pointer to the code (implementation) of the
method. The Objective-C runtime maintains a struct called
“objc_method” for each method of a class. This struct has
the method name, the argument, the return types of the method, and the
“implementation” of the method, which is represented by a
pointer IMP pointing to a C function. Therefore, swizzling basically
involves exchanging the value of the “implementation” field
between the objc_method data of two different methods. Figure 4 and
Figure 5 depict a visualization of the process:
Figure 4: The original selector and its
implementation mapping in class FortitudeViewController before swizzling
Figure 5: The selector and implementation
mapping in class FortitudeViewController after method swizzling
In Figure 4, which shows the state before swizzling,
each selector in Class FortitudeViewController contains a
corresponding pointer IMP that points to its real implementation,
which is a C function behind the scene. For instance, selector1 is an
objc_method struct that contains pointer IMP1.
The
“magic” lies in the availability of three essential C functions in the
Objective-C runtime:
●
method_exchangeImplementations
● class_replaceMethod
● method_setImplementation
The most common and
intuitive way to perform a method swizzling is similar to what is
shown in Figure 6.
Figure 6: Example code showing method swizzling
This code will turn the internal runtime relation of the
relevant methods into the conceptual structure shown in Figure 5. This
effectively allows one to replace an existing implementation of a
function with a new one, thus leading to a new and uncharted behavior
of an app at runtime.
There have been many discussions
about the pitfalls and dangers of utilizing this “black magic.” A
primary focus is to avoid the unintended side effects of using the C
function method_exchangeImplementations (shown above) by instead using
class_replaceMethod and method_setImplementation. Further details are
beyond the scope of this blog post.
Apple does not seem
to have provided any official documentation for the concept of method
swizzling, despite documenting the associated
runtime APIs. However, it is a general consensus within the
developer community that method swizzling is permitted. It should be
noted that to date, Apple does not appear to have rejected an app
during its review process due to the use of method swizzling.
The JavaScriptCore
framework was introduced into iOS at version 7. It allows one to
evaluate JavaScript programs from within a C-based program. It also
lets users insert custom objects to the JavaScript environment. On
iOS, it is similar to an Objective-C wrapper of WebKit’s
JavaScript engine, thus extending the capability and power of
scripting beyond a web client to the whole app.
The
following four classes form the cornerstone of the framework:
● JSVirtualMachine represents the virtual JavaScript
runtime environment that allows JavaScript to run and to be executed.
To initiate a virtual machine instance in Objective-C, one does the
following:
JSVirtualMachine *vm = [[JSVirtualMachine alloc]
init];
● JSContext talks to the above runtime,
provides access to global objects that reside in the context, and
performs the execution of JavaScript code. For example, in
Objective-C, one can initiate a JSContext instance and declare a
variable in the manner shown here:
JSContext *context =
[[JSContext alloc] initWithVirtualMachine:vm];
context[@”name”]
= @”Jean-Luc”;
context[@”organization”] = @”Enterprise”;
● JSValue is the class that represents arbitrary data
in JavaScript. For instance, we have:
JSValue *name =
context[@”name”];
JSValue *organization =
context[@“organization”];
NSLog(@”Captain Name: %@
\nOrganization: %@”, name, organization);
●
JSExport is a protocol that allows one to expose parts of
Objective-C classes and methods to JavaScript. The wrapper created
through this protocol functions as a passthrough between the
Objective-C runtime and the JavaScript runtime. This one object thus
facilitates the sharing between the two execution contexts allowing
code in one environment to change the states of the other.
Rollout exposes to developers only a limited set of JavaScript APIs
that can be permitted in the Objective-C runtime environment. Its API
documentation shows the following essentials:
●
R: the Rollout namespace object that allows integration with
the Rollout SDK, the containing function, and the application’s
runtime. Within which, it offers the functionality of the Foundation C
function NSClassFromString,
as shown in Figure 7.
Figure 7: Portion of Rollout ‘R’ namespace
● ObjcBox: encapsulates Objective-C NSObject
instances. It allows a transformation from an Objective-C instance to
a JavaScript value. There are two important functions, as shown in
Figure 8:
Figure 8: Portion of Rollout ObjcBox namespace
The APIs provided by Rollout and the legitimate use cases they
describe for their hot patching infrastructure are simple, limited,
and benign. However, as with many well-intentioned solutions, the
possibilities of misuse or abuse remain when malicious individuals
think outside the box.
In our blog on JSPatch, we outlined several attack capabilities that
could be carried out against that technology, such as loading
arbitrary public or private frameworks into an app. The types of
capabilities we described for JSPatch also work against Rollout,
though we do not provide specific examples here. Instead, we highlight
a few additional scenarios specific to Rollout to avoid
duplication.
Example 1: Load arbitrary private
frameworks and utilize unauthorized private APIs
● Targeted private framework:
/System/Library/PrivateFrameworks/CoreRecents.framework
●
Targeted private API: [[CRRecentContactLibrary defaultInstance]
maxDateEventsPerRecentContact]
Figure 9 and Figure 10
show sample exploitation code and the associated console output
loading the private framework CoreRecents.framework.
Figure 9: Sample exploitation code for
loading a private framework
Console Output:
Figure 10: Sample console output showing
successful load of the framework
Both this example and the following ones make use of
Apple iOS private APIs. The pros and cons of the use of these private
APIs by third party apps has been at the center of much debate. In general, common
sense suggests that the use of Apple’s private APIs by third party
apps is risky due to security risks as well as stability concerns (for
example, unexpected behavior if Apple changes the internals of the
private APIs). Despite Apple’s efforts to prohibit the practice of utilizing non-public
APIs, it has proven difficult to identify their use when
developers use obfuscation and other even more clever and
sophisticated maneuvers.
That said, when an app developer
with malicious intent makes use of these private APIs, the use of the
APIs will leave traces within the app code itself. This means the
malicious code within the app is subject to potential discovery by
Apple or a third party. However, with Rollout’s dynamic hot patching
process, the intent – that is, the malicious code – can be separated
from the app binary itself in the form of a hot patch. Rollout, as a
remote hot patching solution, is not the only means one can resort to
separating private API calls from the app binary, but it lowers the
bar for malware developers to achieve so.
Example 2: Load arbitrary public frameworks and utilize
unauthorized private APIs
● Targeted public framework:
/System/Library/Frameworks/AVFoundation.framework
● Targeted
private API: [AVCaptureDevice devices]
Figure 11 and
Figure 12 show sample code used to successfully access the iPhone’s
cameras and microphone.
Figure 11: Example exploit code loading public
framework to access the private AVCaptureDevice API
Console outputs three devices: Back Camera; Front
Camera; iPhone Microphone.
Figure 12: Console output showing access
to the iPhone cameras and microphone
Example 3: Test device for the presence of a targeted app
The ability for one app to check for the presence of
another app raises both privacy and security concerns (for example,
checking for the presence of an app in order to exploit it). The
primary method for obtaining a list of installed apps is through the
private API [LSApplicationWorkspace allInstalledApplications]. As we
have seen, use of these private APIs is prohibited by Apple’s
Developer Program License Agreement.
Some app developers
have sought other means to determine installed apps without using
Apple’s private APIs. For example, iHasApp used the public API
[UIApplication canOpenURL:] to identify installed apps based on their supported URL schemes.
Unfortunately, the extensive usage of the API and associated detection
method in a large volume of apps resulted in iHasApp and its derived framework being shut down by Apple, and
the API being flagged during the app store vetting process.
However, Rollout eliminates this constraint because the API can
be called via a hot patch outside of the app itself.
Figure 13 and Figure 14 show sample code using canOpenURL: to detect
installed apps.
Figure 13: Sample exploit code calling canOpenUrl
Figure 14: Console output showing app detection
Example 4: Make phone calls to premium numbers without consent
By utilizing the public API [UIApplication openURL:],
one can launch the native mobile phone app and make a phone call to an
arbitrary premium number. This activity would be immediately visible
to the user when the phone app interface was unexpectedly displayed.
However, use of the exploit could be fine-tuned by applying
environmental checks (for example, only initiate calls when the user
is asleep) and maintaining a status of long running background process
through background modes.
Figure
15 and Figure 16 show sample code for dialing a premium number and the
successful connection.
Figure 15: Sample exploit code used to dial a
premium phone number
Figure 16: Console output showing
successful call
Example 5: Take screenshot without informing the user
Figure 17, Figure 18, and Figure 19 show that through
the patch, one can take screenshots of the current foreground screen
by utilizing non-public API [UIImage createSnapshotWithRect:] without
the user’s knowledge. The screenshots are saved in the sandbox of the
application, which can be further exflitrated outside of the device.
Figure 17: Sample exploit code showing
the use of private API [UIImage createSnapshotWithRect:] to capture
the screen
Figure 18: Console output showing
that the captured screenshot has been saved to the
sandbox
Figure 19: App sandbox content showing
the captured images
All of the above tests were performed on a device that runs iOS 8.4.
Apple has released a number of iOS versions through the years to fix
and close security holes reported by both industry practitioners and
academic researchers. Most of the private or public APIs that could
have been abused are protected through various access controls (e.g.,
entitlements to the Address Book) in newer
versions of iOS. However, the reality is that there are a significant
number of users who are not keeping their devices’ OS version
up-to-date. The ramifications are that “old” attacks through private
APIs, which are ineffective against iOS 8.4 or iOS 9, would still be
effective against some devices.
In our earlier blog on JSPatch, we highlighted
three general attack scenarios using an iOS remote hot-patching
vector. Of these, two are still present on Rollout in a similar
fashion:
1. Precondition: 1) Embedded 3rd party ad SDK
is malicious.
a. Consequences: ad SDK has the right to write
to the database, which allows it to change the behavior of the
app.
2. Precondition: 1) App developer is malicious.
a. Consequences: app developers can perform stealthy persistent but
temporary actions against the user including by utilizing Private
APIs.
It has been pointed out that an app developer with malicious
intent will strive to find a way to distribute their malicious app
regardless of the particular framework used. That is, no existing
distribution method can fully guard against malicious intent. While we
agree with this statement, we also believe it is important to
understand how different distribution methods may help or hinder a
malicious developer in deploying their malicious code. A developer
wishing to distribute a malicious app through the App Store would need
to slip the malicious code past the review process. The third-party
hot patching frameworks developed to date do not include any review
process, so it helps to understand how malicious patches could be
distributed and where (or whether) they could be detected.
A risk of hot patching frameworks is that because patches can
be deployed ‘on the fly’, a developer could distribute a legitimate
app, temporarily deploy a patch to carry out specific malicious
activity, and then deploy another patch to revert the app back to its
normal, non-malicious behavior. Because this activity can occur
automatically in the background, users are highly unlikely to notice
the change, and replacement of the malicious patch with a “clean” one
could leave little evidence that anything suspicious had
occurred.
To put the threat scenario in perspective, we
provide a visualization of such an attack to reinforce the concept and
facilitate understanding.
Synopsis
Our fictional app FortitudeSeries was a new release of an iOS
app that allows one to add filters to selected photos from the device
photo gallery and save the edited photos back to the gallery. In order
to offer the user a better experience with quality performance and
stable software, we decided to use the Rollout.io service to maintain
the ability to remotely hot-patch bugs and security issues should they
be discovered in the future.
After testing several
patches, we identified several actions we could take outside of what
the app was originally designed for. We first tried saving an original
copy of all the filtered photos in the sandbox, and it was a quick
success. We then became curious about the photos the user does not
select for filtering, so we issued a new patch to capture a screenshot
of the user’s photo gallery. This too was simple to achieve.
Production
Our fictional attack is demonstrated through three stages to
show the following scenarios:
● Stage 1:
Rollout patching is disabled in the backend. FortitudeSeries only
exhibits its legitimate behavior. A user selects a photo from the
photo gallery by pressing the button “Select A Photo”. Once the photo
is selected, the console outputs “Filtering the selected image” and
the photo gallery view is dismissed. The app’s Documents directory
does not hold any data, therefore, it remains empty. Figure 20 shows
the source code of the main view controller of FortitudeSeries.
Figure 20: Objective-C code for
the core implementation of fictional app FortitudeSeries
● Stage 2: Rollout patch is enabled with the
code shown in Figure 21. The user restarts the app and performs the
same sequence of actions. The app’s Documents directory keeps a record
of the selected photos and labels them with the timestamp of the photo
that was selected.
Figure 21: Rollout patch code for
saving a copy of the user selected photo in the sandbox
● Stage 3: Rollout patch is enabled with
different code, as shown in Figure 22. The user restarts the app and
performs the same sequence of actions described above. The app takes a
screenshot of the photo gallery and saves a copy to the sandbox
Documents directory using the same naming scheme presented
above.
Figure 22: Rollout patch code for
capturing a screenshot of the photo gallery in stealth
Once the data is in the sandbox of the app, the app may
deal with it however it wants. A conceivable approach is to exfiltrate
it to a developer-controlled server. It should not be surprising that
this can be done via a Rollout patch script that executes at runtime
without Apple’s knowledge.
The operation of the demo is
therefore done in the following three stages:
●
Stage 1: Develop FortitudeSeries in Objective C and Rollout;
deploy it to a user device to allow the user filter selected photos;
check the Rollout patch; perform the expected actions on the installed
app; check the console log; check the sandbox Documents
directory;
● Stage 2: Enable Rollout patch with script
for scenario I; restart the app; perform the expected actions on the
installed app; check the console log; check the sandbox Documents
directory;
● Stage 3: Comment out the patch script for
scenario I and enable script for scenario II; restart the app; perform
the expected actions on the installed app; check the console log;
check the sandbox Documents directory.
Primed with the
above depiction, it should be easy to understand the recorded demo
below even without a narrative.
The chances of a successful man-in-the-middle (MITM) attack through
the use of poor encryption (or no encryption) of the patch script
content can be reduced significantly through secure implementation of
the app and any supporting hot patching framework.
To
prevent patches from being tampered with, Rollout invested in the
following security measures:
● The app retrieves the
patch data from Rollout.io server through HTTPS. This significantly
lowers the chances of being a target of MITM attacks.
● The
patch data is signed by a Rollout.io private key and therefore can
only be decrypted by a key that’s known to the iOS app.
The above protection ensures that data is secure in transmission.
However, once the patch data lands on the device, it is decrypted
accordingly and stored in the sandbox in plaintext. Figure 23 shows
the directory #APP_SANDBOX/Library/Caches/#APP_ID containing a
specific database Cache.db that contains data resulting from the hot
patch network communications.
Figure 23: File structure view of
the directory encompasses the database of patch data
All patches that have been pushed to production and
received by the client app are stored as a record in the table
cfurl_cach_receiver_data as shown in Figure 24.
Figure 24: DB table
cfurl_cach_receiver_data containing all records of production patches
Each patch is stored in the receiver_data column in JSON
format. The JavaScript code is mapped to the key “configuration” in
based64 format. For example, the highlighted data blob in Figure 24
contains the based64 encoded content shown in Table 1:
Table 1: base64 content from patch database
Its corresponding ASCII format is the data is shown in
Figure 25.
Figure 25: Decoded base64 content
Given Rollout’s existing security measures such as HTTPS
and asymmetric encryption, as well as iOS’s sandbox, this weakness is
a minor issue. Since there are other attack vectors that can be more
easily exploited (for example those described in our threat scenario I
and II), a third party library may be less motivated to tamper the
patch to their advantage. Should circumstances change and one chooses
to do, this weakness is really to be leveraged.
Rollout’s web site states that its product is “trusted by thousands
of mobile app developers”. As Rollout provides a solution for a
problem that is unique to iOS developers, we can speculate that all
its customers are iOS app developers at this point. Though a few have
been highlighted on their main page, the exact number of App
Store-approved apps that use Rollout SDK is unknown. We performed a
scan using FireEye’s infrastructure in late 2015 and found 130 apps
that have been or still are in the App Store using Rollout as a remote
hot patching solution. This number has since grown to 245 as of Jan.
19, 2016.
As opposed to apps that adopted JSPatch as
the remote hot patching solution, which are predominantly Chinese apps
for Chinese speaking users, apps that use Rollout are mostly marketed
towards English speaking users. Many offer localization for a variety
of languages. There are no distinct features among these apps; they
span a variety of categories including education, social networking,
magazines and newspapers, lifestyle, photo and video, games and more.
Most of the apps have very low user adoption in the App Store at this
point. The most popular app seems to have accumulated a download
record of 62,869 times, while the vast majority have no popularity
rating on file.
At the time of this writing, we have
not confirmed any malicious activity related to any app that uses the
Rollout SDK. We are simply reporting on potential vulnerabilities and
avenues for misconduct that could potentially be exploited when using
this tool.
iOS remote hot-patching through a non-Objective-C language to
effectively evade the Apple review process – a process that has so far
largely led to a safe and clean app ecosystem – is now a reality. Our
analysis has placed JSPatch and Rollout under the spotlight as
examples of two hot patching frameworks with very different characteristics:
Despite differences in their implementation, both are similar in
that they potentially allow a developer to turn an innocuous looking
app into something malicious – all while circumventing Apple’s App
Store vetting process. What’s more, the underlying “biology” is the
same for the two solutions: the combination of JavaScriptCore
framework and method swizzling.
When conducting our research, we contacted Rollout regarding the
issues described in this post. We gratefully acknowledge Rollout’s
responsiveness and assistance in addressing them. As a result, Rollout
has indicated that they will prevent developers from accessing iOS
private APIs and private frameworks in their future releases of the
product so that all patch code is subject to the same types of checks
as those in the Apple review process. With Rollout’s upcoming release,
the attack examples shown here would be thwarted.
The current limitations of the App Store review process and the
desire from developers for a faster solution means that hot patching,
as a process, is unlikely to go away any time soon. We hope that by
describing these underlying risks, patch framework developers will
institute additional security controls to ensure that they are
providing developers with convenience and productivity in iOS app
development all while maintaining a clean and safe ecosystem.
In this ecosystem, iOS users are the least able to protect
themselves and, consequently, the most vulnerable. When it comes to
user security, it is difficult to decide which single stakeholder
should assume the responsibility of maintaining and sustaining a safe
and clean iOS mobile environment. While Apple has come a long way in
keeping its mobile users safe from malware, the task has become
increasingly difficult. It is not outrageous to expect third party
library or framework providers to offer extra security to ensure their
services are not being abused.
While we do not have a definite solution for this complicated issue,
we believe a system that functions as follows could potentially
increase iOS user security: 1) App developers providing to Apple a
list of the third party libraries and frameworks that they use, 2) The
underlying technologies of third party libraries and frameworks being
provided to Apple, and 3) Third party library or framework providers
improving security to ensure their services are used as intended.
Introduction
FireEye mobile researchers recently discovered potentially
“backdoored” versions of an ad library embedded in thousands of iOS
apps originally published in the Apple App Store. The affected
versions of this library embedded funct…
